Model：VGO-180YT
This machine is suitable for automatic bag forming and packing of various granular, block, and piece-shaped materials across different industries, such as food, dietary supplements, hardware, chemicals, plastics, and other sectors.
Key Features:
1. Machine Frame: 304 Stainless Steel With a Matte Sandblasted Surface Finish
2. Center Sealing: Width 10 mm, Tooth Pitch 1.5 mm, Sealing Jaw Length 200 mm
3. Horizontal Sealing: Width 10 mm, Tooth Pitch 1.5 mm, Sealing Jaw Length 180 mm
4. Standard Serrated Cutting Knife
5. Fixed Forming Collar Bracket
6. Full-servo Control System With a 7-inch Resistive Touchscreen
7. Single-side Film Pulling System
8. Sponge Exhaust Device
9、12-Head 0.8L Combination Weigher or 14-Head 0.5L Combination Weigher
|
Model |
VGO-180YT (12-Head 0.8L Combination Weigher) |
VGO-180YT (14-Head 0.5L Combination Weigher) |
|
Packing Speed |
20–80 bags/min |
20–100 bags/min |
|
Packaging Film Width |
100–320 mm |
100–320 mm |
|
Bag Length |
50–190 mm |
50–190 mm |
|
Bag Width |
50–150 mm |
50–150 mm |
|
Center Sealing |
Width: 10 Mm; Tooth Pitch: 1.5 Mm; Sealing Jaw Length: 200 Mm |
|
|
Horizontal Sealing |
Width: 10 Mm; Tooth Pitch: 1.5 Mm; Sealing Jaw Length: 180 Mm |
|
|
Exhaust Device |
Sponge Exhaust Device |
|
|
Control System |
Full-servo Control System With a 10-inch Touchscreen. |
|
|
Machine Weight |
210 kg |
|
|
Machine Dimension (L × W × H) |
1670 × 1250 × 2500 mm |
1650 × 1210 × 2520 mm |
|
Machine Frame |
304 Stainless Steel With a Matte Sandblasted Surface Finish |
|
|
Packaging Materials |
PP, CPP, PVC, PS, EVA, PET, PVDC/PVC, OPP/CPP, etc. |
|
This machine is suitable for automatic bag forming and packing of various granular, block, and piece-shaped materials across different industries, such as food, dietary supplements, hardware, chemicals, plastics, and other sectors.
